Panel PC MV-VT3500-128G40-2T

The MV-VT3500-128G40-2T panel PC from HIKROBOT combines the Core i5 level of the VT3000 series with additional mass storage. An Intel® Core™ i5-8500T computes with 8 GB of memory, while a 128 GB SSD and a 2 TB HDD hold inspection images and result data. The operator works directly at the built-in 15.6-inch touch screen.

Technical data

The display shows 1920 × 1080 pixels at a brightness of 500 cd/m², with a viewing angle of 89° each to the left, right, top and bottom. Under Windows, the capacitive touch screen handles ten touch points at once. Cameras and network connect to four GigE interfaces and four USB 3.0 ports, an external monitor to HDMI. For signals to the controller there are three digital-isolated inputs and eight opto-isolated outputs, for serial connections four RS-232 interfaces with switching to RS-485 and RS-422. The Windows 10 operating system is unactivated.

Operating conditions

The supply is 24 VDC, and typical power consumption is 120 W. Operation is permitted at 0 °C to 50 °C, storage at -30 °C to 70 °C. Relative humidity has to stay between 20% and 80%, and condensation must not occur.

Applications and selection

At the Core i5 level, too, memory stays at 8 GB; keep this in mind when planning the inspection program. Without the hard disk the model is available as MV-VT3500-128G40-NN. More computing power with the same storage comes with the MV-VT3700-128G40-2T with Core i7, less with the MV-VT3300-128G40-2T with Core i3 and the MV-VT3100-128G40-2T with Celeron. We are glad to help with sizing by cameras, image data and cycle time; requests go through the inquiry basket.
