Panel PC MV-VT3300-128G40-NN

The MV-VT3300-128G40-NN panel PC from HIKROBOT is a computer with a built-in 15.6-inch touch screen for image processing and operation at the machine. In the VT3000 series it is the level above the entry model MV-VT3100: an Intel® Core™ i3-8100T works with 8 GB of memory and a 128 GB SSD.

Technical data

Four RS-232 interfaces, switchable to RS-485 or RS-422, as well as three digital-isolated inputs and eight opto-isolated outputs lead to the controller. Cameras and network run over four GigE interfaces, peripherals over four USB 3.0 ports, an external display over HDMI. The display with 1920 × 1080 pixels has a viewing angle of 89° to the left, right, top and bottom; the capacitive touch screen detects ten touch points under Windows. The operating system, Windows 10, is unactivated.

Operating conditions

The MV-VT3300-128G40-NN runs on 24 VDC with a typical power consumption of 120 W. The ambient temperature may be 0 °C to 50 °C in operation and -30 °C to 70 °C in storage; relative humidity has to stay between 20% and 80%, without condensation.

Applications and selection

This variant has only the 128 GB SSD for storage; for an image archive at the machine there is the MV-VT3300-128G40-2T with an additional hard disk. Below it sits the MV-VT3100 with Celeron, above it follow the MV-VT3500 with Core i5 and the MV-VT3700 with Core i7. We are glad to help with sizing cameras and computer level; requests go through the inquiry basket.
