Area scan camera MV-CS023-10GC

Manufacturer part number: MV-CS023-10GC · 306301948

Resolution: 2.3 MP
Pixels: 1920 × 1200
Max. frame rate: 41 fps
Color / mono: Color
Shutter type: Global Shutter
Sensor format: 1/1.2"
Pixel size: 5.86 µm × 5.86 µm
Interface: GigE
Lens mount: C-Mount

Price and availability on request

Quantity

Not sure which model fits?

One of our staff will review your application and recommend the right configuration.

Have your application reviewed

Technical data

Manufacturer part number	MV-CS023-10GC
Type	2.3MP Area Scan Camera, GigE, IMX249, 2nd Generation, Color
Sensor type	CMOS, global shutter
Sensor model	Sony® IMX249
Pixel size	5.86 µm × 5.86 µm
Sensor size	1/1.2"
Resolution	1920 × 1200
Max. frame rate	41 fps @1920 × 1200 Bayer RG 8
Dynamic range	72.6 dB
SNR	44.9 dB
Gain	0 dB to 24 dB
Exposure time	15 µs to 10 sec
Exposure mode	Off/Once/Continuous exposure mode
Mono	Color
Pixel format	Mono 8/10/12, Bayer RG 8/10/10Packed/12/12Packed, YUV422Packed, YUV422_YUYV_Packed RGB 8, BGR 8
Binning	Supports 1 × 1, 2 × 2, 4 × 4
Decimation	Supports 1 × 1, 2 × 2, 4 × 4
Reverse image	Supports horizontal and vertical reverse image output
Data interface	Gigabit Ethernet, compatible with Fast Ethernet
Digital I/O	6-pin P7 connector provides power and I/O, including opto-isolated input × 1 (Line 0), opto-isolated output × 1 (Line 1), bi-directional non-isolated I/O × 1 (Line 2).
Power supply	9 VDC to 24 VDC, supports PoE
Power consumption	Typ. 2.6 W@12 VDC
Lens mount	C-mount
Dimension	29 mm × 29 mm × 42 mm (1.1" × 1.1" × 1.2")
Weight	Approx. 100 g (0.22 lb.)
Ingress protection	IP40 (under proper lens installation and wiring)
Temperature	Working temperature: –30 °C to 60 °C (–22 °F to 140 °F) Storage temperature: –30 °C to 70 °C (–22 °F to 158 °F)
Humidity	20 % RH to 95 % RH (no condensation)
Client software	MVS or third-party software meeting with GigE Vision Protocol
Operating system	32/64-bit Windows 7/10, 32/64-bit Linux
Compatibility	GigE Vision V2.0, GenICam
Certification	CE, RoHS, KC

Data according to the manufacturer's documentation. The current manufacturer datasheet, quotation and order confirmation are authoritative. Errors and changes excepted.

Dimensional drawing
