di-soric
LAT45-6MIU-B5
Manufacturer part number: LAT45-6MIU-B5
- Sensor function
- Distance sensor
- Range
- 300 – 6000 mm
- Light source
- Laser
- Light color
- Red
- Design
- Cuboid
- Switching output
- PNP
- Switching function
- NO/NC switchable
- Connection
- Connector, M12
- Interface
- IO-Link 1.1
- Ingress protection
- IP67
Price and availability on request
Request this item directly by email
Not sure which model fits?
One of our staff will review your application and recommend the right configuration.
Have your application reviewedTechnical data
| Manufacturer part number | LAT45-6MIU-B5 |
|---|---|
| Funktionsprinzip | Optical |
| Bauform | Cuboid |
| Erfassungsbereich | 300 … 6000 mm (90 % reflectance) |
| Schaltfrequenz | 0.3 Hz … 11 Hz |
| Lichtquelle | Laser |
| Schaltausgang | pnp (2x), 200 mA, NO/NC, konfigurierbar |
| Schnittstelle | IO-Link V1.1, COM2, Smart Sensor Profile |
| LED Anzeige | LED green - Status, yellow - switching output |
| Anschluss | Connector, M12, 5-pin |
| Betriebsspannung | 18 … 30 V DC (Supply Class 2) |
| Leerlaufstrom (max.) | 150 mA |
| Schutzklasse | III, operation on safety extra-low voltage |
| Schutzart | IP 67 |
| Umgebungstemperatur Betrieb | -10 … +60 °C |
| Gehäusematerial | Die-cast zinc (black, painted) |
| Gehäuselänge | 52 mm |
| Gewicht | 309 g |
| Produktgruppe | Distance sensor |
| Serie | LAT-45 Hohe Reichweite |
| Farbe | Red |
Data according to the manufacturer's documentation. The current manufacturer datasheet, quotation and order confirmation are authoritative. Errors and changes excepted.
Documents
- Download datasheet
Datasheet di-soric LAT45-6MIU-B5
Datasheet · DE · 1 MB
Description
The LAT-45 impresses with a long range of up to 10 m. The sensor is equally suited to measuring and switching applications. The LAT-45 is operated either via the keypad or IO-Link, and its easy-to-read display shows the measured values. Good independence from color and surface allows distance measurement on many surfaces.
- IO-Link
- Long range
- Good independence from color and surface
- Red laser for easy alignment
- Measured value shown on the display
- Easy operation
- Rugged metal housing
