di-soric

ISDP-70-NSLK-K-BS

Manufacturer part number: ISDP-70-NSLK-K-BS

Sensor function: Tube sensor
Switching distance: 14 mm
Switching output: NPN
Switching function: Normally open (NO)
Connection: Pigtail, 0.04 m
Housing material: Plastic (PC)
Ingress protection: IP67

Price and availability on request

Quantity

Not sure which model fits?

One of our staff will review your application and recommend the right configuration.

Have your application reviewed

Technical data

Manufacturer part number	ISDP-70-NSLK-K-BS
Funktionsprinzip	Inductive
Bauform	Cuboid
Schaltabstand (SN)	14 mm
Ansprechzeit	0.20 ms
Auswertung	Dynamisch
Schaltausgang	npn, 200 mA, NO
LED Anzeige	LED green - operation, yellow - switching output
Anschluss	Pigtail, 0.04 m, M12, 3-pin
Betriebsspannung	10 … 35 V DC (Supply Class 2)
Leerlaufstrom (max.)	25 mA
Spannungsfall (max.)	2 V
Isolationsspannungsfestigkeit	500 V
Schutzklasse	III, operation on safety extra-low voltage
Schutzart	IP 67
Umgebungstemperatur Betrieb	-25 … +70 °C
Gehäusematerial	Plastic (PC)
Material Kabel	PUR
Gehäuselänge	70 mm
Besonderheiten	Unempfindlich
Produktgruppe	Tube sensor
Serie	ISDP Dynamisch
IO-Link	No

Data according to the manufacturer's documentation. The current manufacturer datasheet, quotation and order confirmation are authoritative. Errors and changes excepted.

Documents

Datasheet di-soric ISDP-70-NSLK-K-BS
Datasheet · DE · 806 KB
Download datasheet

Description

Our hose sensors with dynamic evaluation have a high resolution and a short response time. Metallic contamination is suppressed automatically. The sensors can be retrofitted and fixed in place with cable ties. They are characterized by low weight, a compact design and a high degree of protection (IP 67), and have a metal connector.

- Standard sensitivity

- Dynamic operating principle

- Automatic suppression of metallic contamination

- Compact design

- Low weight

- Cable with M12 connector

- Mounting slot for easy installation

- Cable ties included
