Logistik Code-Reader-Set MV-PD010003-12C-8C

HIKROBOT

Logistik Code reader kit MV-PD010003-12C-8C

Manufacturer part number: MV-PD010003-12C-8C

Code type: 1D and 2D
Resolution: 12 MP
Focal length / optics: 8 mm
Working / focus range: 780 mm
Communication: Ethernet

Price and availability on request

Quantity

Not sure which model fits?

One of our staff will review your application and recommend the right configuration.

Have your application reviewed

Technical data

Manufacturer part number	MV-PD010003-12C-8C
Type	12MP Logisitc Code Reading Set
Symbologies	1D codes: Code 39, Code 93, Code 128, Codabar, EAN 2D codes: QR Code, Data Matrix
Focal length	8 mm
Best working distance	780 mm
Field of view (range)	730 mm × 550 mm @10 mil
Depth of field	400 mm
Resolution	4024 × 3036
Max. frame rate	9.6 fps @4024 × 3036
Aperture	F2.8 to F16
Center illuminance	9000 lux @1000 mm
Uniformity	0.56
Luminous flux	5900 lm
Light source wavelength	420 nm to 730 nm
Color temperature	6500 K
Mono/color	Color
Pixel format	Mono 8, Bayer 8, YUV 422 Packed, YUV422(YUYV)
Data interface	Gigabit Ethernet
Digital I/O	6-pin connecting terminal provides power and I/O, including opto-isolated input × 1 (Line 0), and bi-directional non-isolated I/O × 1 (Line 2)
Power supply	24 VDC
Max. power consumption	44 W
Dimension (without lens)	164.2 mm × 149.6 mm × 159.1 mm (6.5" × 5.9" × 6.3")
Weight (without lens)	Approx. 1420 g (3.1 lb.)
Temperature	Working temperature: 0 °C to 50 °C (32 °F to 122 °F) Storage temperature: -30 °C to 70 °C (-22 °F to 158 °F)
Humidity	20 % to 80 % RH, non-condensing
Client software	MVS, Code Platform
Operating system	32/64-bit Windows XP/7/10
Certification	CE, KC

Data according to the manufacturer's documentation. The current manufacturer datasheet, quotation and order confirmation are authoritative. Errors and changes excepted.

Dimensional drawing

Maßzeichnung Logistik Code-Reader-Set MV-PD010003-12C-8C

Documents

Datasheet HikRobot Logistik Code-Reader-Set MV-PD010003-12C-8C
Datasheet · DE · 428 KB
Download datasheet
Technical drawing HikRobot Logistik Code-Reader-Set MV-PD010003-12C-8C
Technical drawing · DE · 5 MB
Download
Software / Firmware V4.0.15 HikRobot Logistik Code-Reader-Set MV-PD010003-12C-8C
Software / firmware · DE · 2 MB
Download
Manual HikRobot Logistik Code-Reader-Set MV-PD010003-12C-8C
Manual · DE · 1 MB
Download

Accessories

Data cables(25)

HIKROBOT

Standard GigE Datenkabel (RJ45-RJ45), 30 m

RJ45 (with locking stud) · 30 m

Datenkabel

HIKROBOT

Standard GigE Datenkabel (RJ45-RJ45), 5 m

RJ45 (with locking stud) · 5 m

Datenkabel

HIKROBOT

Hochflex GigE Datenkabel (RJ45 Winkel-RJ45), 15 m

RJ45 (with locking stud),Bend (up) · 15 m

Datenkabel

HIKROBOT

Hochflex GigE Datenkabel (RJ45-RJ45), 30 m

RJ45 (with locking stud) · 30 m

Datenkabel

HIKROBOT

Hochflex GigE Datenkabel (RJ45-RJ45), 7 m

RJ45 (with locking stud) · 7 m

Datenkabel

HIKROBOT

SuperFlex GigE Datenkabel (RJ45-RJ45), 10 m

RJ45 (with locking stud) · 10 m

Datenkabel

HIKROBOT

Hochflex GigE Datenkabel (RJ45-RJ45), 10 m

RJ45 (with locking stud) · 10 m

Datenkabel

HIKROBOT

Standard GigE Datenkabel (RJ45 Winkel-RJ45), 15 m

RJ45 (with locking stud),Bend (up) · 15 m

Datenkabel

HIKROBOT

Standard GigE Datenkabel (RJ45 Winkel-RJ45), 5 m

RJ45 (with locking stud),Bend (up) · 5 m

Datenkabel

HIKROBOT

Hochflex GigE Datenkabel (RJ45 Winkel-RJ45), 5 m

RJ45 (with locking stud),Bend (up) · 5 m

Datenkabel

HIKROBOT

Standard GigE Datenkabel (RJ45-RJ45), 1 m

RJ45 (with locking stud) · 1 m

Datenkabel

HIKROBOT

Standard GigE Datenkabel (RJ45-RJ45), 60 m

RJ45 (with locking stud) · 60 m

Datenkabel

HIKROBOT

SuperFlex GigE Datenkabel (RJ45-RJ45), 3 m

RJ45 (with locking stud) · 3 m

Datenkabel

HIKROBOT

SuperFlex GigE Datenkabel (RJ45-RJ45), 7 m

RJ45 (with locking stud) · 7 m

Datenkabel

HIKROBOT

Hochflex GigE Datenkabel (RJ45-RJ45), 5 m

RJ45 (with locking stud) · 5 m

Datenkabel

HIKROBOT

Standard GigE Datenkabel (RJ45-RJ45), 10 m

RJ45 (with locking stud) · 10 m

Datenkabel

HIKROBOT

Hochflex GigE Datenkabel (RJ45-RJ45), 3 m

RJ45 (with locking stud) · 3 m

Datenkabel

HIKROBOT

SuperFlex GigE Datenkabel (RJ45-RJ45), 5 m

RJ45 (with locking stud) · 5 m

Datenkabel

HIKROBOT

Hochflex GigE Datenkabel (RJ45-RJ45), 15 m

RJ45 (with locking stud) · 15 m

Datenkabel

HIKROBOT

SuperFlex GigE Datenkabel (RJ45-RJ45), 15 m

RJ45 (with locking stud) · 15 m

Datenkabel

HIKROBOT

Standard GigE Datenkabel (RJ45-RJ45), 3 m

RJ45 (with locking stud) · 3 m

Datenkabel

HIKROBOT

Standard GigE Datenkabel (RJ45 Winkel-RJ45), 3 m

RJ45 (with locking stud),Bend (up) · 3 m

Datenkabel

HIKROBOT

Standard GigE Datenkabel (RJ45-RJ45), 15 m

RJ45 (with locking stud) · 15 m

Datenkabel

HIKROBOT

Hochflex GigE Datenkabel (RJ45 Winkel-RJ45), 3 m

RJ45 (with locking stud),Bend (up) · 3 m

Datenkabel

HIKROBOT

Standard GigE Datenkabel (RJ45-RJ45), 7 m

RJ45 (with locking stud) · 7 m

Datenkabel

Description

Key Feature - Adopts code recognition technology. - Supports acquisition and integration of data and images. - Supports local data storage, uploading, and tracking. - Adopts integrated structure to facilitate installation. - Centralized light with high luminescence efficiency. - Long service life time, and stable performance. - Provides real-time and effective data for logistics related enterprises.
