OPT
Line light OPT-LSNLC356-G
Manufacturer part number: OPT-LSNLC356-G
Series: OPT-LSNLC-Serie (passiv gekühlte koaxiale Zeilenbeleuchtungen)
- Illuminated area
- 338 mm?
- Light color
- Green
- Optical layout
- Koaxial?
- Cooling
- Passive / natural convection
Price and availability on request
Request this item directly by email
Not sure which model fits?
One of our staff will review your application and recommend the right configuration.
Have your application reviewedTechnical data
| Manufacturer part number | OPT-LSNLC356-G |
|---|---|
| Color | green |
| Current | 2.4 A |
| Power | 57.6 W |
| Dimensions (L x W x H) | 356 × 32 × 151.5 mm |
| Product series | OPT-LSNLC (coaxial, passively cooled) |
| Optical layout | Koaxial |
| Beam characteristic | Highly directional |
| Illuminated area | 338 mm |
| Cooling | Passive / natural convection |
| Connection | ZQ GX16M-6B |
| Housing length | 356 mm |
Data according to the manufacturer's documentation. The current manufacturer datasheet, quotation and order confirmation are authoritative. Errors and changes excepted.
Dimensional drawing
Documents
Accessories
Beleuchtungskabel(4)
Description
OPT-LSNLC356-G is a coaxial line light from the OPT-LSNLC series by OPT. Key figures according to the manufacturer: illumination range 338 mm at 356 mm housing length, light color green, power consumption 57.6 W, rated current 2.4 A, passive cooling, connector ZQ GX16M-6B.
The OPT-LSC series, in which OPT lists this model, is according to the manufacturer a coaxial line light with high light output. It illuminates mirror-like webs perpendicularly from the camera axis and makes surface defects visible as dark spots.
