Falcon

Line light FLLN-Si240-R24

Manufacturer part number: FLLN-Si240-R24

Series: FLLN-240

Emitting area: 240 × 15 mm
Light color: Red, 626 nm
Operating mode: Continuous and strobe
Optical design / beam angle: Line focus
Connection: JST SMR-03V
Supply: 24 V
Power consumption: 9.60 W

Price and availability on request

Quantity

Not sure which model fits?

One of our staff will review your application and recommend the right configuration.

Have your application reviewed

Technical data

Manufacturer part number	FLLN-Si240-R24
Type	Bar light
Version	Linie
Color	Red
Wavelength	626 nm
Size	268 × 20 × 45 mm
Working Distance	10 – 100 mm
Operating Voltage	24 V
Power Consumption	9.60 W
Current	0.4 A
Ripple Voltage	≤ Vs ± 2 %
Reverse Battery Protection	Yes
Total Number of LED	42
LED Package	SMD
LED Life Span Continous	20000 hours
LED Life Span Strobe	approx. > 50,000 hours (to 50 % remaining intensity at 25 °C ambient temperature)
Eye safety	Exempt group
Housing	Aluminum
Weight	364
Connector	JST SMR-03V
Connector Pin	Pin 1: +; Pin 2: not connected; Pin 3: -
Cable	500 mm
Operating Condition	0–35 °C, 20–85 % relative humidity
Operating Temperature	after 60 minutes with compress air cooling 55 °C (without 75 °C)
Cooling Method	Mounting on a machine part for heat dissipation
Operating mode	Continuous and strobe
Max. pulse duration	10 ms
Max. duty cycle	10 %
Emitting area	240 × 15 mm
Optical design	Line focus

Data according to the manufacturer's documentation. The current manufacturer datasheet, quotation and order confirmation are authoritative. Errors and changes excepted.

Dimensional drawing

Documents

Datasheet FLLN-Si240-R24
Datasheet · EN · 194 KB
Download datasheet

Description

The FLLN-Si240-R24 from Falcon is a bar light with red light at 626 nm. The working distance is 10 to 100 mm; supply voltage is 24 V. Power consumption is 9.6 W; connection is made through a JST SMR-03V connector. The attached cable is 500 mm long; the housing is made of aluminum.
